NRND

RE 15 Ø15 mm, Precious Metal Brushes CLL, 1.6 Watt

Part number 118645

RE 15 Ø15 mm, Precious Metal Brushes CLL, 1.6 Watt
Price scales Quantity Price per unit
Prices excluding VAT and shipping costs 1-4 €134.00
5-19 €118.31
20-49 €100.10
from 50 On request

NRND (Not Recommended for New Designs): These products continue to be available, but are not recommended for new projects. Our sales team will be happy to suggest alternatives.

Specifications

Values at nominal voltage
Nominal voltage 6 V
No load speed 10000 rpm
No load current 14.9 mA
Nominal speed 3610 rpm
Nominal torque (max. continuous torque) 2.25 mNm
Nominal current (max. continuous current) 0.333 A
Stall torque 4.17 mNm
Stall current 0.596 A
Max. efficiency 72 %
Characteristics
Terminal resistance 10 Ω
Terminal inductance 0.19 mH
Torque constant 7.04 mNm/A
Speed constant 1360 rpm/V
Speed / torque gradient 1960 rpm/mNm
Mechanical time constant 10.9 ms
Rotor inertia 0.532 gcm²
Thermal data
Thermal resistance housing-ambient 35 K/W
Thermal resistance winding-housing 8.2 K/W
Thermal time constant winding 4.19 s
Thermal time constant motor 214 s
Ambient temperature -20...+65 °C
Max. winding temperature +85 °C
Mechanical data
Bearing type sleeve bearing
Max. speed 11000 rpm
Axial play 0.05 - 0.15 mm
Radial play 0.014 mm
Max. axial load (dynamic) 0.2 N
Max. force for press fits (static) 20 N
Max. radial load 0.5 N, 5 mm from flange
Other specifications
Number of pole pairs 1
Number of commutator segments 5
Number of autoclave cycles 0
Product
Weight 20 g
  • Operating Range

    Continuous operation range


    Short term operation range


Description

maxon DC motors are high-quality motors fitted with powerful permanent magnets. The “heart” of the motor is the worldwide patented ironless rotor. For you, this means cutting-edge technology in compact, powerful and low inertia drives.
